The Joyetech Cuboid Mod and Cubis Tank



Hi folks- the all new 200watt Joyetech Cuboid Temperature Control Mod can accommodate Nickel, Titanium and Stainless Steel coils and has a TCR Mode. I tested this unit out for 7 days straight…. what do I think? Join me as I do a complete review with vapor test. Also visit my website for additional info and coupon codes.

The Cuboid Mod

The new CUBOID mod (shipping January 8th 2016) has a stainless steel body and a simple, straight up appearance, including an advanced OLED display that offers more than Joyetech’s top-notch eVic-Mini horizontal display. The display shows two battery icons that shows the amount of power left in each of the two 18650 cells used with the Cuboid.

It features wattage up to 150W with support for temperature control and variable wattage. It is firmware upgradeable as well, so you can take your Cuboid to 200W via the VT Software. (Windows only) The new firmware V3.10 for the Cuboid increases the maximum output up to 200W. Also Temp-SS316 and TCR are available. The Cuboid also features a 510-thread that is compatible with just about every tank and RDA.

Features and Specs:

Features and Specs:

  • Dimensions: 3-5/8″ x 1-5/8″ x 1-1/8″
  • Stainless Steel 510 Threads
  • Temperature Control: Nickel, Titanium, Stainless Steel 316 and TCR Mode
  • Output Wattage: 1-150W
  • Temperature Control Range: 100 – 315C / 200 – 600F
  • Resistance Range: 0.05-1.5ohm for Variable Temperature Mode
  • Resistance Range: 0.1-3.5ohm for Variable Wattage Mode
  • Requires (2) 18650 High Amp Batteries (sold separately)
  • Upgradable Firmware
  • Multi-Colored 0.96-inch OLED Screen
  • Dual Battery Display Bar
  • New Slip-Open Battery Cover for Simple Battery Changes
  • Micro USB Port for Firmware Updates and Charging
  • **We recommend an external charger for optimal charging**
  • Reverse Battery Polarity Protection
  • New Firmware V3.10 for Cuboid Available

The Cubis Tank

Joyetech’s latest high-end tank is the Cubis, made for the Cuboid mod, but works extremely well on other mods. The CUBIS has an innovative, leak resistant cup design. The atomizer head replacements and e-liquid refills are easily achieved by removing the top section from the tank. Thankfully, their is a mark on the side of the tank indicating the Fill Level.

The CUBIS uses the all-new BF Stainless Steel SS316 atomizer heads which are designed forgreatflavor and vapor production. The BF SS316 CUBIS atomizer heads can be used for both variable wattage and SS316 temperature control mode.

The CUBIS is easily disassembled for easy cleaning. An adjustable hidden airflow control valve is found behind the removable top cap for adjusting the draw to your own personal preference.

Features and Specs:

  • Dimensions: 2-3/8″ x 7/8″ (Including Drip Tip and Threads)
  • 22mm Diameter
  • 510 Threaded
  • Top Filled Design
  • Innovative Cup Design
  • Hidden Adjustable Airflow Valve
  • 3.5ml e-Liquid Capacity
  • BF Stainless Steel 316 Atomizer Heads for Temperature Control or Variable Wattage Mode
  • BF Clapton Atomizer heads for Variable Wattage Only
  • Insulated Drip Tip

Info below taken from Joyetech website:

Cuboid applies Variable Temperature Control system with firmware V3.0 and 150W output, having Temp-SS316 and customized TCR available now. It is powered by two replaceable 18650 cells with the new slip-open cover.

Multiple colors, 0.96-inch OLED screen and the new dual-battery bar display make it more practical and attractive catering to your preference.

Upgradeable firmware enables it always up-to-date. Now you can upgrade your Cuboid to 200W via VT Software.

Based on the previous Temp-SS mode, we developed the new Temp-SS316 mode.

Use the Joyetech BF-SS316 atomizer head (0.5ohm/1.0ohm) for the Cubis tank.
